Air-Jet Covered Yarn

Novel air-jet technology achieving a high level of covering efficiency

Air-Jet Covered Yarn (ACY)

The general process of this yarn is to use the principle of compressed air to entangle and combine the matching yarn (spandex) with the main yarn. The method is similar to the principle of air texturing. Hsin Jung's process can change the main yarn and matching yarn according to customer's needs to produce customized ACY.

APPLICATIONS

  • Warp-knitted Uppers
  • Circular-knitted Uppers
  • Weft-knitted Uppers
  • Knit/Woven Fabric
  • Women’s Bottom

OUR ADVANTAGE

Hsin Jung Fiber uses Swiss-manufactured covering equipment that adopts novel air-jet technology to create air-jet covered yarn (ACY). Compared with the conventional yarn covering technique, the new air-jet technique achieves substantially higher efficiency. With the spirit of professional craftsmanship that insists on consistent high quality for 40 years, Hsin Jung Fiber integrates electronic systems with the precise control of manufacturing parameters to achieve an efficient manufacturing process while ensuring high product quality, achieving a reproducibility rate of 99%. Therefore, an effective solution that facilitates alleviating the constraints related to cost, time, and quantity can be provided for customers.

SPECIFICATION

Standard Type Luster
Spandex(D) Polyester (D/F) FDY DTY Bright Semi-dull Full-dull
15
20
30
40
55
70
120
140		 20/24   v   v
30/24   v   v
40/24   v   v
50/72   v   v
75/36   v   v
75/72   v   v
75/144   v   v
100/36   v   v
100/96   v   v
150/48   v   v
150/96   v   v
150/144   v   v
300/96   v   v
75/72/2   v   v
75/144/2   v   v
300/96   v   v
Standard Type Luster
Spandex(D) Nylon 6 (D/F) FDY DTY Bright Semi-dull Full-dull
15
20
30
40
55
70
120
140		 15/5   v   v
17/10   v v v
20/7   v   v
20/24   v   v v
30/10   v   v
30/24   v   v
30/36   v     v
40/14   v   v v
40/34   v   v v
40/48   v   v
50/48   v   v
70/24   v v v v
70/48   v v v v
70/72   v   v v
100/24   v   v
140/48   v   v
140/96   v   v v
140/144   v   v v
200/48   v   v
210/72   v   v
Standard Type Luster
Spandex(D) Nylon 6.6 (D/F) FDY DTY Bright Semi-dull Full-dull
15
20
30
40
55
70
120
140		 20/7   v   v
20/20   v   v v
30/10   v   v
30/20   v   v
40/34   v   v v
70/34   v   v v
70/68   v   v v
100/34   v   v
140/136   v   v v

※ Note: This table is a common specification, and a customized service is also available.
